The MassWateR package includes several “utility” functions (using the
util prefix) that are used inside other functions to
accomplish routine tasks. Although these functions will typically not be
used by themselves, they may be useful for custom analyses. The full
list of utility functions can be viewed on the functions
page. Some of these are described below.
Most of the utility functions require only the results data, data
quality objectives file for accuracy, or the site metadata file. Note
that all of the utility functions require data as input, whereas most of
the primary MassWateR functions can accept a file path or the data. The
fset argument also does not apply to the utility
functions.
library(MassWateR)
# import results data
respth <- system.file("extdata/ExampleResults.xlsx", package = "MassWateR")
resdat <- readMWRresults(respth)
#> Running checks on results data...
#> Checking column names... OK
#> Checking all required columns are present... OK
#> Checking valid Activity Types... OK
#> Checking Activity Start Date formats... OK
#> Checking depth data present... OK
#> Checking for non-numeric values in Activity Depth/Height Measure... OK
#> Checking Activity Depth/Height Unit... OK
#> Checking Activity Relative Depth Name formats... OK
#> Checking values in Activity Depth/Height Measure > 1 m / 3.3 ft... OK
#> Checking Characteristic Name formats... OK
#> Checking Result Values... OK
#> Checking for non-numeric values in Quantitation Limit... OK
#> Checking QC Reference Values... OK
#> Checking for missing entries for Result Unit... OK
#> Checking if more than one unit per Characteristic Name... OK
#> Checking acceptable units for each entry in Characteristic Name... OK
#>
#> All checks passed!
# import accuracy data
accpth <- system.file("extdata/ExampleDQOAccuracy.xlsx", package = "MassWateR")
accdat <- readMWRacc(accpth)
#> Running checks on data quality objectives for accuracy...
#> Checking column names... OK
#> Checking all required columns are present... OK
#> Checking column types... OK
#> Checking no "na" in Value Range... OK
#> Checking for text other than <=, ≤, <, >=, ≥, >, ±, %, AQL, BQL, log, or all... OK
#> Checking overlaps in Value Range... OK
#> Checking gaps in Value Range... OK
#> Checking Parameter formats... OK
#> Checking for missing entries for unit (uom)... OK
#> Checking if more than one unit (uom) per Parameter... OK
#> Checking acceptable units (uom) for each entry in Parameter... OK
#> Checking empty columns... OK
#>
#> All checks passed!
# import site metadata
sitpth <- system.file("extdata/ExampleSites.xlsx", package = "MassWateR")
sitdat <- readMWRsites(sitpth)
#> Running checks on site metadata...
#> Checking column names... OK
#> Checking all required columns are present... OK
#> Checking for missing latitude or longitude values... OK
#> Checking for non-numeric values in latitude... OK
#> Checking for non-numeric values in longitude... OK
#> Checking for positive values in longitude... OK
#> Checking for missing entries for Monitoring Location ID... OK
#>
#> All checks passed!Fill data outside of detection or quantitation limit
The utilMWRlimits() function replaces any text
qualifiers in the "Result Value" column of the results file
that are outside of detection ("BDL" or "AQL")
with appropriate numeric values. The values are replaced with those from
the "Quanitation Limit" column, if present, otherwise the
"MDL" or "UQL" columns from the data quality
objectives file for accuracy are used. Values as "BDL" use
one half of the appropriate limit. The output only includes rows with
the activity type as "Field Msr/Obs" or
"Sample-Routine" and is filtered by the chosen parameter.
The function can be useful for analysis because the measurements are
returned as numeric values (e.g., for plotting).
utilMWRlimits(resdat = resdat, accdat = accdat, param = 'TP')
#> # A tibble: 48 × 18
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Sample-Routine 2022-05-15 00:00:00
#> 2 ABT-077 Sample-Routine 2022-05-15 00:00:00
#> 3 ABT-301 Sample-Routine 2022-05-15 00:00:00
#> 4 ABT-312 Sample-Routine 2022-05-15 00:00:00
#> 5 DAN-013 Sample-Routine 2022-05-15 00:00:00
#> 6 ELZ-004 Sample-Routine 2022-05-15 00:00:00
#> 7 HOP-011 Sample-Routine 2022-05-15 00:00:00
#> 8 NSH-002 Sample-Routine 2022-05-15 00:00:00
#> 9 ABT-026 Sample-Routine 2022-06-12 00:00:00
#> 10 ABT-062 Sample-Routine 2022-06-12 00:00:00
#> # ℹ 38 more rows
#> # ℹ 15 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <dbl>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>, …Filter results data
The utilMWRfilter() function filters rows in the results
data by parameter, date range, sites, result attributes, and/or location
groups. No other changes to the data are made other than filtering the
relevant rows based on the input. The function is designed to provide
informative errors, e.g., the available result attributes will be shown
in the error if the attribute provided is invalid. Filtering by location
group requires the site metadata file.
# filter by parameter, date range
utilMWRfilter(resdat = resdat, param = 'DO', dtrng = c('2022-06-01', '2022-06-30'))
#> # A tibble: 11 × 18
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Field Msr/Obs 2022-06-12 00:00:00
#> 2 ABT-062 Field Msr/Obs 2022-06-12 00:00:00
#> 3 ABT-077 Field Msr/Obs 2022-06-12 00:00:00
#> 4 ABT-144 Field Msr/Obs 2022-06-12 00:00:00
#> 5 ABT-237 Field Msr/Obs 2022-06-12 00:00:00
#> 6 ABT-301 Field Msr/Obs 2022-06-12 00:00:00
#> 7 ABT-312 Field Msr/Obs 2022-06-12 00:00:00
#> 8 DAN-013 Field Msr/Obs 2022-06-12 00:00:00
#> 9 ELZ-004 Field Msr/Obs 2022-06-12 00:00:00
#> 10 HOP-011 Field Msr/Obs 2022-06-12 00:00:00
#> 11 NSH-002 Field Msr/Obs 2022-06-12 00:00:00
#> # ℹ 15 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <chr>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>,
#> # `Project ID` <chr>, `Local Record ID` <chr>, `Result Comment` <chr>
# filter by parameter, site
utilMWRfilter(resdat = resdat, param = 'DO', site = c('ABT-026', 'ABT-062', 'ABT-077'))
#> # A tibble: 13 × 18
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Field Msr/Obs 2022-05-15 00:00:00
#> 2 ABT-077 Field Msr/Obs 2022-05-15 00:00:00
#> 3 ABT-026 Field Msr/Obs 2022-06-12 00:00:00
#> 4 ABT-062 Field Msr/Obs 2022-06-12 00:00:00
#> 5 ABT-077 Field Msr/Obs 2022-06-12 00:00:00
#> 6 ABT-026 Field Msr/Obs 2022-07-17 00:00:00
#> 7 ABT-062 Field Msr/Obs 2022-07-17 00:00:00
#> 8 ABT-077 Field Msr/Obs 2022-07-17 00:00:00
#> 9 ABT-026 Field Msr/Obs 2022-08-14 00:00:00
#> 10 ABT-062 Field Msr/Obs 2022-08-14 00:00:00
#> 11 ABT-077 Field Msr/Obs 2022-08-14 00:00:00
#> 12 ABT-026 Field Msr/Obs 2022-09-11 00:00:00
#> 13 ABT-077 Field Msr/Obs 2022-09-11 00:00:00
#> # ℹ 15 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <chr>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>,
#> # `Project ID` <chr>, `Local Record ID` <chr>, `Result Comment` <chr>
# filter by parameter, result attribute
utilMWRfilter(resdat = resdat, param = 'DO', resultatt = 'DRY')
#> # A tibble: 27 × 18
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Field Msr/Obs 2022-05-15 00:00:00
#> 2 ABT-077 Field Msr/Obs 2022-05-15 00:00:00
#> 3 ABT-301 Field Msr/Obs 2022-05-15 00:00:00
#> 4 ABT-312 Field Msr/Obs 2022-05-15 00:00:00
#> 5 DAN-013 Field Msr/Obs 2022-05-15 00:00:00
#> 6 ELZ-004 Field Msr/Obs 2022-05-15 00:00:00
#> 7 HOP-011 Field Msr/Obs 2022-05-15 00:00:00
#> 8 NSH-002 Field Msr/Obs 2022-05-15 00:00:00
#> 9 ABT-026 Field Msr/Obs 2022-08-14 00:00:00
#> 10 ABT-062 Field Msr/Obs 2022-08-14 00:00:00
#> # ℹ 17 more rows
#> # ℹ 15 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <chr>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>, …
# filter by parameter, location group, date range
utilMWRfilter(resdat = resdat, param = 'DO', sitdat = sitdat,
locgroup = 'Assabet', dtrng = c('2022-06-01', '2022-06-30'))
#> # A tibble: 7 × 19
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Field Msr/Obs 2022-06-12 00:00:00
#> 2 ABT-062 Field Msr/Obs 2022-06-12 00:00:00
#> 3 ABT-077 Field Msr/Obs 2022-06-12 00:00:00
#> 4 ABT-144 Field Msr/Obs 2022-06-12 00:00:00
#> 5 ABT-237 Field Msr/Obs 2022-06-12 00:00:00
#> 6 ABT-301 Field Msr/Obs 2022-06-12 00:00:00
#> 7 ABT-312 Field Msr/Obs 2022-06-12 00:00:00
#> # ℹ 16 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <chr>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>,
#> # `Project ID` <chr>, `Local Record ID` <chr>, `Result Comment` <chr>, …Summarize parameters by group
The utilMWRsummary() function summarizes results data
for a parameter, either across all rows or by arbitrary row groups,
e.g., mean concentrations for sites across dates. The
utilMWRlimits() function must be used first and a grouping
variable can be specified using group_by() from the dplyr package
(included with MassWateR). The default is to summarize as the mean or
geometric mean based on information in the data quality objective file
for accuracy.
library(dplyr)
# fill BDL, AQL
resdat <- utilMWRlimits(resdat = resdat, accdat = accdat, param = "DO")
# identify site as grouping variable
dat <- resdat %>%
group_by(`Monitoring Location ID`)
# arithmetic means
utilMWRsummary(dat = dat, accdat = accdat, param = "DO", confint = TRUE)
#> # A tibble: 11 × 4
#> `Monitoring Location ID` lov hiv `Result Value`
#> <chr> <dbl> <dbl> <dbl>
#> 1 ABT-026 6.62 7.99 7.31
#> 2 ABT-062 6.00 9.54 7.77
#> 3 ABT-077 7.88 9.36 8.62
#> 4 ABT-144 7.22 8.86 8.04
#> 5 ABT-237 3.81 9.27 6.54
#> 6 ABT-301 6.00 8.08 7.04
#> 7 ABT-312 6.36 8.10 7.23
#> 8 DAN-013 2.89 9.83 6.36
#> 9 ELZ-004 3.48 6.56 5.02
#> 10 HOP-011 4.43 9.83 7.13
#> 11 NSH-002 4.00 8.77 6.38
# geometric means
utilMWRsummary(dat = dat, accdat = accdat, param = "E.coli", confint = TRUE)
#> # A tibble: 11 × 4
#> `Monitoring Location ID` lov hiv `Result Value`
#> <chr> <dbl> <dbl> <dbl>
#> 1 ABT-026 6.61 8.03 7.29
#> 2 ABT-062 6.19 9.71 7.75
#> 3 ABT-077 7.89 9.38 8.60
#> 4 ABT-144 7.27 8.89 8.04
#> 5 ABT-237 4.34 9.68 6.48
#> 6 ABT-301 6.01 8.15 7.00
#> 7 ABT-312 6.34 8.18 7.20
#> 8 DAN-013 2.71 11.8 5.67
#> 9 ELZ-004 3.64 6.60 4.90
#> 10 HOP-011 4.48 10.4 6.83
#> 11 NSH-002 4.08 9.20 6.13Alternative summary options can be used with the sumfun
argument and include "mean", "geomean",
"median", "min", or "max". Using
"mean" or "geomean" will override any
information in the accuracy file. Additionally, confidence intervals can
only be returned if sumfun is "auto",
"mean", or "geomean". Here, the median is
returned.
# median E. coli
utilMWRsummary(dat = dat, accdat = accdat, param = "E.coli", confint = FALSE, sumfun = 'median')
#> # A tibble: 11 × 4
#> `Monitoring Location ID` `Result Value` lov hiv
#> <chr> <dbl> <lgl> <lgl>
#> 1 ABT-026 7.58 NA NA
#> 2 ABT-062 7.59 NA NA
#> 3 ABT-077 8.94 NA NA
#> 4 ABT-144 7.85 NA NA
#> 5 ABT-237 5.92 NA NA
#> 6 ABT-301 7.07 NA NA
#> 7 ABT-312 7.42 NA NA
#> 8 DAN-013 8 NA NA
#> 9 ELZ-004 4.46 NA NA
#> 10 HOP-011 7.8 NA NA
#> 11 NSH-002 7.06 NA NAGet surface measurements only
The utilMWRfiltersurface() function returns only surface
measurements from the results data. The function will filter the results
where "Activity Depth/Height Measure" is less than or equal
to 1 meter or 3.3 feet or the
"Activity Relative Depth Name" is "Surface",
where the latter takes precedent.
utilMWRfiltersurface(resdat = resdat)
#> # A tibble: 49 × 18
#> `Monitoring Location ID` `Activity Type` `Activity Start Date`
#> <chr> <chr> <dttm>
#> 1 ABT-026 Field Msr/Obs 2022-05-15 00:00:00
#> 2 ABT-077 Field Msr/Obs 2022-05-15 00:00:00
#> 3 ABT-301 Field Msr/Obs 2022-05-15 00:00:00
#> 4 ABT-312 Field Msr/Obs 2022-05-15 00:00:00
#> 5 DAN-013 Field Msr/Obs 2022-05-15 00:00:00
#> 6 ELZ-004 Field Msr/Obs 2022-05-15 00:00:00
#> 7 HOP-011 Field Msr/Obs 2022-05-15 00:00:00
#> 8 NSH-002 Field Msr/Obs 2022-05-15 00:00:00
#> 9 ABT-026 Field Msr/Obs 2022-06-12 00:00:00
#> 10 ABT-062 Field Msr/Obs 2022-06-12 00:00:00
#> # ℹ 39 more rows
#> # ℹ 15 more variables: `Activity Start Time` <chr>,
#> # `Activity Depth/Height Measure` <chr>, `Activity Depth/Height Unit` <chr>,
#> # `Activity Relative Depth Name` <chr>, `Characteristic Name` <chr>,
#> # `Result Value` <dbl>, `Result Unit` <chr>, `Quantitation Limit` <chr>,
#> # `QC Reference Value` <chr>, `Result Measure Qualifier` <chr>,
#> # `Result Attribute` <chr>, `Sample Collection Method ID` <chr>, …
